Bassett B27140 MSE-3 Center Cutting General Purpose Regular Length Single End Square End End Mill, 5/8 in Dia Cutter, 1-1/4 in Length of Cut, 3 Flutes, 5/8 in Dia Shank, 3-1/2 in OAL, Bright
Bassett B27140 MSE-3 Center Cutting General Purpose Regular Length Single End Square End End Mill, 5/8 in Dia Cutter, 1-1/4 in Length of Cut, 3 Flutes, 5/8 in Dia Shank, 3-1/2 in OAL, Bright
Bassett End Mill, Center Cutting General Purpose Regular Length Single End Square End, Series: MSE-3, 5/8 in Diameter Cutter, 3-1/2 in Overall Length, 1-1/4 in Length of Cut, 3 Flutes, Spiral Flute, 5/8 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Straight Shank, Solid Carbide, Bright
Features
- 10% Cobalt submicron grain carbide substrate
- 30 deg right hand spiral, right hand cut helix designed for maximum chip clearance
- 3-Flute end mills provide a compromise between the chip clearance of a 2-flute tool and the rigidity and wear resistance of a 4-flute tool, especially useful for many slotting operations
- Applicable on steel, cast iron, high temperature alloys, non-ferrous materials, low carbon steels and plastics
Specifications
Bassett End Mill, Center Cutting General Purpose Regular Length Single End Square End, Series: MSE-3, 5/8 in Diameter Cutter, 3-1/2 in Overall Length, 1-1/4 in Length of Cut, 3 Flutes, Spiral Flute, 5/8 in Shank Diameter, Right Hand Cutting Direction, 30 deg Helix Angle, Straight Shank, Solid Carbide, Bright
