Cleveland® C58445 1096 General Purpose Heavy Duty Spiral Flute Machine Tap, Right Hand Cutting, 5/16-18 Thread, H3 Thread Limit, Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Steam Oxide, HSS
Cleveland® C58445 1096 General Purpose Heavy Duty Spiral Flute Machine Tap, Right Hand Cutting, 5/16-18 Thread, H3 Thread Limit, Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Steam Oxide, HSS
Cleveland® C58445 1096 General Purpose Heavy Duty Spiral Flute Machine Tap, Right Hand Cutting, 5/16-18 Thread, H3 Thread Limit, Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Steam Oxide, HSS

Click to enlarge
CLEVELAND
C58445

Cleveland® C58445 1096 General Purpose Heavy Duty Spiral Flute Machine Tap, Right Hand Cutting, 5/16-18 Thread, H3 Thread Limit, Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Steam Oxide, HSS

Cleveland® C58445 1096 General Purpose Heavy Duty Spiral Flute Machine Tap, Right Hand Cutting, 5/16-18 Thread, H3 Thread Limit, Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, Steam Oxide, HSS

Catalog Number:
Manufacturer: Greenfield
Brand: CLEVELAND
Item ID: CTDT C58445
MPN: C58445
Min Order Qty: 1

Cleveland® Spiral Flute Machine Tap, General Purpose Heavy Duty, Series: 1096, Measurement System: Imperial, Ground/UNC Thread Standard, 5/16-18 Thread, Bottoming Chamfer, 3 Flutes, HSS, Steam Oxide, Class of Fit: 2B, Right Hand Cutting Direction, 0.69 in Thread Length, 2.72 in Overall Length, 0.318 in Shank Diameter, 3/8 in Shank Length, Right Hand Flute Direction, H3 Thread Limit, Steel and Stainless Steel Material Application, No Through Coolant

Sold As: 1/PK

Specifications

Chamfer Type
Bottoming
Class of Fit
2B
Cutting Direction
Right Hand
Finish/Coating
Steam Oxide
Flute Direction
Right Hand
Material Application
Steel and Stainless Steel
Material
HSS
Measurement System
Imperial
Number of Flutes
3
Overall Length
2.72 in
Series
1096
Shank Diameter
0.318 in
Shank Length
3/8 in
Thread Length
0.69 in
Thread Limit
H3
Thread Size
5/16-18
Thread Standard
Ground/UNC
Through Coolant (Yes/No)
No
Type
General Purpose Heavy Duty

Cleveland® Spiral Flute Machine Tap, General Purpose Heavy Duty, Series: 1096, Measurement System: Imperial, Ground/UNC Thread Standard, 5/16-18 Thread, Bottoming Chamfer, 3 Flutes, HSS, Steam Oxide, Class of Fit: 2B, Right Hand Cutting Direction, 0.69 in Thread Length, 2.72 in Overall Length, 0.318 in Shank Diameter, 3/8 in Shank Length, Right Hand Flute Direction, H3 Thread Limit, Steel and Stainless Steel Material Application, No Through Coolant
