Fluke® 5066006 Clamp Meter, 200 mA, 600 V AC/V DC, 20000 Ohm, 50 to 400 Hz, LCD Backlit Display
Fluke® 5066006 Clamp Meter, 200 mA, 600 V AC/V DC, 20000 Ohm, 50 to 400 Hz, LCD Backlit Display
Fluke® 5066006 Clamp Meter, 200 mA, 600 V AC/V DC, 20000 Ohm, 50 to 400 Hz, LCD Backlit Display

Click to enlarge
FLUKE ELECTRONICS
5066006

Fluke® 5066006 Clamp Meter, 200 mA, 600 V AC/V DC, 20000 Ohm, 50 to 400 Hz, LCD Backlit Display

Fluke® 5066006 Clamp Meter, 200 mA, 600 V AC/V DC, 20000 Ohm, 50 to 400 Hz, LCD Backlit Display

Catalog Number:
Manufacturer: Fluke Electronics
Brand: FLUKE ELECTRONICS
Item ID: FLUK 5066006
MPN: 5066006
Min Order Qty: 1
Minimum order quantities may apply.

Fluke®, 5066006, Clamp Meter, 200 mA, 600 V AC/V DC Electrical Rating, 20000 Ohm Resistance, 50 to 400 Hz Frequency, LCD Backlit Display, 2% +/-3 Digits Voltage Accuracy, Safety Rating: CAT IV 600 V, CAT III 600 V, AA Alkaline Battery Power Source, -20 to 55 deg C Operating, 1.97 in H x 3.94 in W x 8 in L Dimensions, Yellow

Features

  • Rugged, compact advanced insulation resistance tester for electrical contractors and industrial and commercial electricians
  • Automatically calculates Polarization Index and Dielectric Absorption Ratio
  • Makes repetitive tests simple and easy with a Compare (Pass/Fail) function
  • Offers multiple insulation test voltages: 50 V, 100 V, 250 V, 500 V, and 1000 V
  • Includes live circuit detection to prevent insulation test if voltage >30 V is detected
  • Includes auto-discharge of capacitive voltage for added user protection
  • Provides lo-ohms earth-bond continuity (200 mA)
  • Simplifies repetitive or hard-to-reach testing with the remote test probe
  • Saves battery power with auto power off
  • Features CAT IV 600 V overvoltage category rating
  • Comes with remote probe, test leads, test probes, alligator clips and one-year warranty
  • Accepts optional Fluke TPAK magnetic hanging system to free your hands for other work

Specifications

Color
Yellow
Dimensions
1.97 in H x 3.94 in W x 8 in L
Display Type
LCD Backlit
Electrical Ratings
200 mA, 600 V AC/V DC
Frequency Rating
50 to 400 Hz
Operating Temperature
-20 to 55 deg C
Power Source
AA Alkaline Battery
Resistance
20000 Ohm
Safety Rating
CAT IV 600 V, CAT III 600 V
Voltage Accuracy
2% +/-3 Digits

Fluke®, 5066006, Clamp Meter, 200 mA, 600 V AC/V DC Electrical Rating, 20000 Ohm Resistance, 50 to 400 Hz Frequency, LCD Backlit Display, 2% +/-3 Digits Voltage Accuracy, Safety Rating: CAT IV 600 V, CAT III 600 V, AA Alkaline Battery Power Source, -20 to 55 deg C Operating, 1.97 in H x 3.94 in W x 8 in L Dimensions, Yellow
