Marson® Klik-Fast® SBL6-12 Klik-Fast® High Quality Non-Structural Open End Blind Rivet, Steel, 3/16 in Dia Rivet, 0.95 in L, 0.626 to 0.75 in Grip, Large Flange Button Head

Marson® Klik-Fast® SBL6-12 Klik-Fast® High Quality Non-Structural Open End Blind Rivet, Steel, 3/16 in Dia Rivet, 0.95 in L, 0.626 to 0.75 in Grip, Large Flange Button Head

Catalog Number:
Manufacturer: HOWMET FASTENING SYSTEMS
Brand: HOWMET FASTENING SYSTEMS
Item ID: HUCK 506160
MPN: 506160
Min Order Qty: 1
Minimum order quantities may apply.

Marson® Klik-Fast® Blind Rivet, High Quality Non-Structural Open End, Series: Klik-Fast®, Steel Material - Body/Mandrel, 3/16 in Rivet Diameter, 0.95 in Length, 0.626 to 0.75 in Grip, Large Flange Button Head, #11 Drill, 0.615 in Dia x 0.09 in H Head, 0.192 to 0.196 in Diameter Hole, 610 lb Shear Strength, 870 lb Tensile Strength, Plated Body/Coated Mandrel

Features

  • For blind fastening where there is no access to opposite side of work
  • Simple to install
  • Provides greater bearing surface for fastening soft and brittle facing materials and oversize facing holes
  • Works well with soft materials, where the increased flange diameter protects the integrity of the application
  • High grip strength and no surface distortion
  • Applicable on hard and soft materials
  • High strength
  • Vibration and tamper resistant

Specifications

Drill Size
#11
Finish
Plated Body/Coated Mandrel
Grip Range
0.626 to 0.75 in
Head Size
0.615 in Dia x 0.09 in H
Head Type
Large Flange Button
Hole Diameter
0.192 to 0.196 in
Length
0.95 in
Material - Body/Mandrel
Steel
Rivet Diameter
3/16 in
Series
Klik-Fast®
Shear Strength
610 lb
Tensile Strength
870 lb
Type
High Quality Non-Structural Open End

Marson® Klik-Fast® Blind Rivet, High Quality Non-Structural Open End, Series: Klik-Fast®, Steel Material - Body/Mandrel, 3/16 in Rivet Diameter, 0.95 in Length, 0.626 to 0.75 in Grip, Large Flange Button Head, #11 Drill, 0.615 in Dia x 0.09 in H Head, 0.192 to 0.196 in Diameter Hole, 610 lb Shear Strength, 870 lb Tensile Strength, Plated Body/Coated Mandrel
