REED MANUFACTURING
03120

Reed 03120 Hinged Cutter, 2 to 4 in Nominal, Ergonomic Grip Rubber Handle

Reed 03120 Hinged Cutter, 2 to 4 in Nominal, Ergonomic Grip Rubber Handle

Catalog Number:
Manufacturer: REED MANUFACTURING
Brand: REED MANUFACTURING
Item ID: REED 03120
MPN: 03120
Min Order Qty: 1

Hinged Pipe Cutters feature four wheels to cut steel, stainless steel, cast and ductile iron with only 90deg to 110deg handle swing. Only 4" (125 mm) clearance is required around pipe. Strong guide fingers ensure perfect wheel alignment for square cuts. A closed 360deg frame on the hinged pipe cutter forces all energy into cutting the pipe for maximum efficiency. There is no shower of sparks in this cold cut. REED has the only 4-wheel pipe cutter that tracks every time and the only one recommended for ductile iron, steel, and stainless steel to Schedule 100. This tool is a REED invention.

Reed Hinged Cutter, 2 to 4 in Nominal, Tool Steel Blade, 22 in Overall Length, Ductile Iron Body, Ergonomic Grip Handle, Rubber Handle, Applicable Materials: SCH 40 Steel and Stainless Steel

Sold As: 1/PK
Springfield

Features

  • Pipe Cutter with hinge is a REED invention that needs only 4 in (102 mm) of clearance around pipe
  • Efficient handle swing of only 90deg to 110deg
  • Ships with cutter wheels installed for cutting steel and stainless steel pipe

Specifications

Applicable Materials
SCH 40 Steel and Stainless Steel
Blade Material
Tool Steel
Body Material
Ductile Iron
Handle Material
Rubber
Handle Type
Ergonomic Grip
Nominal Capacity
2 to 4 in
Overall Length
22 in

Hinged Pipe Cutters feature four wheels to cut steel, stainless steel, cast and ductile iron with only 90deg to 110deg handle swing. Only 4" (125 mm) clearance is required around pipe. Strong guide fingers ensure perfect wheel alignment for square cuts. A closed 360deg frame on the hinged pipe cutter forces all energy into cutting the pipe for maximum efficiency. There is no shower of sparks in this cold cut. REED has the only 4-wheel pipe cutter that tracks every time and the only one recommended for ductile iron, steel, and stainless steel to Schedule 100. This tool is a REED invention.

Reed Hinged Cutter, 2 to 4 in Nominal, Tool Steel Blade, 22 in Overall Length, Ductile Iron Body, Ergonomic Grip Handle, Rubber Handle, Applicable Materials: SCH 40 Steel and Stainless Steel
